Description
Specifications:
Carrier frequency: UHF610-670MHz
Number of channels: 200
Channel interval: 300KHz
Receiving mode: CPU controlled automatic
Frequency stability: within ±0.005%
Frequency MAX deviation: ±50KHz
Modulation mode: FM
S/N: ≥105dB
Audio frequency response: 40-18k Hz
Receiver Power supply: AC110-240V
Transmitter output power: 15mW or 5mW
Transmitter power supply: 2 X AA1.5V
Service time: more than 5 hours at 15mW,
more than 8 hours at 5mW.
Operation temperature: -10℃~ 40℃
Features:
1,Using UHF ultra-high frequency band, less interference than the traditional VHF band, more reliable transmission.
2,DPLL digital phase-locked loop multi-channel frequency synthesis technology, within 60MHz frequency bandwidth,
with 300KHz channel interval, provides up to 200 channel choices, convenient for multiple machines to use at the same time,
easy to avoid all kinds of interference.
3,Advanced automatic frequency synchronization technology, even if the frequency of the transmitter and receiver is messed up,
you only need to click, the transmitter will automatically chase receiver frequency and adjust consistent, easy to use.
4,Working distance: open environment: 80-100 meters, complex environment: 50-80 meters.
